Isolates the common volume between two solids. This command is like the Solid Exclusive Or command, but the common volume is cut out of the two solids and becomes a separate solid, rather than be subtracted from them.

Point 1: First Solid

Point 2: Second Solid

The common volume between the two solids is cut out and becomes a third solid. The only portions that remain as the two original solids are portions that were exclusive to those solids before the command was executed.



NOTE: For best results, the solids should overlap rather than meet exactly at a face
